Card & Pin Door Access System ( AC-2020A )

AC-2020A (Metal, Touch screen):

3000 Cards/Users (10000 cards type can be customized)
Work Voltage: DC12V > Unlock Current: $1.5A
Static Current: $60 mA Reading Range: 2-10cm; Ambient Temperature: -10~70 Ambient Humidity: 20%~80% Electricity lock output: <=3A Alarm output: <=20A
Output short circuit protection time: <=100uS Open time: 0~99 seconds (adjustable) Colorway: Copper and silver optional
Size: 78.7*78.7*18.6mm
Three Opening mode: card, card+pin or pin
